PPGI / PPGL Colour Coated Coils
Pre-painted steel combines a galvanized (GI) or galvalume (GL) substrate with factory-applied primer and top coat — a ready-to-form, weather-resistant product for roofing, sandwich panels and appliances, available in RAL colours.
Supply range
Specification
Typical supply window. Final dimensions and tolerances are confirmed per order against mill capability and the ordered standard.
- Thickness
- 0.12 – 1.0 mm
- Width
- 600 – 1250 mm
- Substrate
- GI Z40 – Z275 · GL AZ50 – AZ150
- Paint system
- PE · SMP · HDP · PVDF
- Top coat
- Typically 15 – 25 µm
- Back coat
- Typically 5 – 10 µm
- Colours
- RAL range · wrinkle · matt · printed
Grade cross-reference
Order in your standard.
Approximate equivalents across the standards our buyers specify most. Always confirm chemical and mechanical requirements before ordering.
| Use | JIS (Japan) | EN (Europe) | ASTM (USA) | China | BIS (India) |
|---|---|---|---|---|---|
| Commercial | CGCC | DX51D+Z (EN 10169) | A755 on A653 CS | TDC51D+Z | IS 14246 |
| Structural | CGC340 – CGC440 | S250GD – S350GD | A755 on A653 SS | TS350GD+Z | IS 14246 |
Applications
Where it goes.
- Roofing & wall cladding
- Sandwich & insulated panels
- Cold rooms & warehouses
- Home appliances
- Partitions & shutters
- Signage & interior panels
Packing & documents
Seaworthy, every time.
Protective PE film on request, VCI and plastic wrap, steel outer cover, edge and ring protectors, steel bands; coils eye-to-sky on pallets or eye-to-wall.
- Mill test certificate (EN 10204 3.1) with heat numbers
- Commercial invoice, packing list & bill of lading
- Certificate of origin
- Third-party inspection report on request
FAQ
Common questions.
PPGI or PPGL — what is the difference?
PPGI uses a zinc (GI) substrate; PPGL uses an aluminium-zinc (galvalume) substrate with better heat and corrosion resistance — often preferred for long-life roofing.
Which paint system for the Gulf?
SMP or HDP offer better UV and chalking resistance than standard polyester; PVDF is the premium option for long colour retention.
What is the minimum order per colour?
It varies by mill — typically one coil run per colour and thickness. Share your colour list and we will confirm.
Need PPGI this quarter?
Send grade, size, quantity and destination port — we'll return a firm offer.
Request a quote
