Galvanized Coils & Sheets
Hot-dip galvanized steel carries a zinc coating that protects the base metal from corrosion — essential in the Gulf climate and in coastal African markets. We supply GI coils, plain sheets and corrugated roofing profiles across a full range of coating masses.
Supply range
Specification
Typical supply window. Final dimensions and tolerances are confirmed per order against mill capability and the ordered standard.
- Thickness
- 0.12 – 4.0 mm
- Width
- 600 – 1500 mm
- Coating
- Z40 – Z275 g/m² (both sides)
- Spangle
- Regular · minimised · zero
- Passivation
- Chromated · chrome-free · anti-finger
- Coil ID
- 508 / 610 mm
- Coil weight
- 3 – 10 MT
Grade cross-reference
Order in your standard.
Approximate equivalents across the standards our buyers specify most. Always confirm chemical and mechanical requirements before ordering.
| Use | JIS (Japan) | EN (Europe) | ASTM (USA) | China | BIS (India) |
|---|---|---|---|---|---|
| Commercial | SGCC | DX51D+Z | A653 CS-B | DX51D+Z | IS 277 GP |
| Forming / drawing | SGCD | DX52D · DX53D | A653 FS / DS | DX52D+Z | IS 277 GPD |
| Structural | SGC340 – SGC440 | S250GD – S350GD | A653 SS Gr.37 – 50 | S350GD+Z | IS 277 YS 250–350 |
Applications
Where it goes.
- Roofing & wall cladding
- HVAC ducting
- Cable trays & electrical
- Purlins, studs & light-gauge framing
- Solar mounting structures
- Substrate for PPGI / PPGL
Packing & documents
Seaworthy, every time.
VCI paper, plastic film and galvanized/steel outer wrap, inner and outer rings, edge protectors and steel bands. Sheets in sealed bundles on skids; corrugated sheets bundled by length.
- Mill test certificate (EN 10204 3.1) with heat numbers
- Commercial invoice, packing list & bill of lading
- Certificate of origin
- Third-party inspection report on request
FAQ
Common questions.
Which zinc coating should I choose?
Z80 – Z120 is common for indoor and ducting use; Z180 – Z275 is recommended for roofing, coastal and outdoor exposure in the GCC and Africa.
What is spangle?
The crystal pattern of the zinc. Regular spangle is standard; zero or minimised spangle gives a smoother surface for painting.
Can you supply corrugated roofing sheets?
Yes — GI and PPGI corrugated and trapezoidal profiles in standard lengths, subject to profile availability at the mill.
